Model Name |
AMG-17IPPC02T3 |
|
Screen Size |
17" |
|
Active Display Area (mm) |
337.920(H)x270.336(V) |
|
Pixel Pitch (mm) |
0.264(H)x0.264(V) |
|
Display Mode |
Normally White |
|
Display Resolution (pixel) |
1280X1024 |
|
Contrast Ratio |
1000:1 |
|
Display Color |
16.7M color |
|
Brightness (CD/㎡) |
Max:1200(Light Sensor) |
|
Backlight |
CCFL/LED |
|
Viewing Angles (CR =10) |
170Hx160V |
|
Response Time(Typ.Tr+Tf) |
5ms |
|
Signal Connector |
VGA/DVI |
|
Power Consumption |
DC 12V |
|
Dimension(VxHxT) |
440.6X354.6X56.7 |
|
Operating Temperature |
0～50℃ |
|
Storage Temperature |
-20～60℃ |
|
Relative Humidity |
5(%RH)～90(%RH) |
|
Touch Screen |
PCAP Touch(10 points) |
