Model Name |
AMG-19OPHA02N2 |
Screen Size |
19" |
Active Display Area (mm) |
376.32 (H) x 301.06 (V) |
Pixel Pitch (mm) |
0.294 (H) x 0.294 (V) |
Display Mode |
Normally white |
Display Resolution (pixel) |
1280x1024 |
Contrast Ratio |
1000:1 |
Display Color |
16.7M |
Brightness (CD/㎡) |
250 |
Backlight |
LED |
Viewing Angles (CR =10) |
170 (H); 160 (V) |
Response Time(Typ.Tr+Tf) |
5ms |
Signal Connector |
VGA/DVI |
Power Consumption |
DC 12V |
Dimension(VxHxT) |
398.5x326.5x30 |
Operating Temperature |
0~50℃ |
Storage Temperature |
-20~60℃ |
Relative Humidity |
5(%RH)~90(%RH) |
Touch Screen |
Optional |
